UP20T – Tilt Mount Helm

UP20T – Tilt Mount Helm

• Built-in lock valve for positive rudder lock • Integrated relief valve for over-pressure protection • Easy accessible lock valve and shaft seal for replacement ...

• Built-in lock valve for positive rudder lock
• Integrated relief valve for over-pressure protection
• Easy accessible lock valve and shaft seal for replacement
• 3/4” tapered stainless steel shaft
• Corrosion proof composite housing
• For use with UC95-OBF, UC68-OBS and UC69-I cylinders only
• Includes 90° adjustable fittings for 3/8” hose
• Tilt mechanism: X82 tilt range of 48° and five locking positions
KIT F (optional): remote fill adapter

Label Value
Mounting Tilt mount with X82
Displacement/revolution 20 cc - 1.2 cu.in
No. of pistons 5
Relief valve setting 70 Bar - 1000 PSI
Max. wheel diameter 406 mm (16")
Weight 3,9 kg (8.5 lbs)
CodiceModelloDescrizione

Model Part Number Description
UP20T 43181A Tilt mount helm with X82
