UC81-OBF Front Mount Cylinder

UC81-OBF Front Mount Cylinder

• UC81-OBF – Balanced: the number of wheel turns lock-to-lock is equal port to starboard and vice-versa. • Replaceable cylinder end caps • According to ...

• UC81-OBF – Balanced: the number of wheel turns lock-to-lock is equal port to starboard and vice-versa.
• Replaceable cylinder end caps
• According to the different engines UC81-OBF can be installed either starboard or port

Label Value
Volume 81 cc - 4.9 cu.in
Output force 222 kg (489 lbs)
Inside diameter 27,4 mm (1.08")
Stroke 186 mm (7.3")
Fittings for high pressure flex hose 3/8"
Bleed fittings DN5 quick connect

Model Part Number Description
UC81-OBF 42654N Front mount cylinder for outboard engines up to 115 hp
